PROGRAMMING

19. THREE–DIMENSIONAL

CUTTING FUNCTION

B–63664EN/02

401

7) Immediately after G98, three–dimensional transform is performed on

nozzle movement based on the current position of the nozzle. So,

unexpected changes may occur to the nozzle position. Before issuing

G98, therefore, position the fourth and fifth axes in such a point where

changes to the nozzle position can be foreseen.

(It is recommended that the fourth and fifth axes be set to the origin

before the nozzle is returned to the basic position.)

8) A three–dimensional coordinate transform command (G68) can be

issued in the G98 mode.

15601

#6 #5 #4 #3

RDC

#2 #1 #0

[Data type] Bit

RDC In three–dimensional conversion, the rotation around the fourth and fifth

axes is:

0 : In a direction in which the distance of movement becomes shorter.

When a software OT area is encountered if the axis rotation is

performed in the shorter–distance direction, however, the rotation is

performed in the opposite direction.

1 : Not the same as usual. For the fourth axis, the direction of travel

before the conversion is assumed. If there are two solutions, the one

nearer the amount of travel before the conversion is selected. The

solution for the fifth axis is determined with the solution selected for

the fourth axis.

15623

Angle at which rotation is assumed to be only plane rotation in three–dimensional

conversion

[Data type] Two–word

[Unit of data] 0.001 deg

[Valid data range] 0 to 89999

If, in three–dimensional conversion, the difference between the

inclination of the plane containing three reference points (P1, P2, and P3)

and that of the plane containing three target points (Q1, Q2, and Q3) is

equal to or less than the angle specified in this parameter, the inclination

difference is ignored and the rotation is assumed to be only rotation in the

X–Y plane.

If this parameter is 0, this compensation process is not executed.
