PROGRAMMING
19. THREE–DIMENSIONAL
CUTTING FUNCTION
B–63664EN/02
411
5483
Limit value of movement that is executed at the normal direction angle of a
preceding block
[Data type] 2–word
[Unit of data]
Increment system IS–B Unit
Millimeter input 0.001 mm
Inch input 0.0001 inch
[Valid data range] 1 to 99999999
This parameter sets the limit value of movement at the normal direction
angle of a preceding block.
For details, refer to the parameter manual.
5490 Axis number of a rotary axis for torch turning control
[Data type] Byte
[Unit of data] None
[Valid data range] 1 to the maximum number of controlled axes
Set the axis number of a rotary axis used for torch turning control.
#7
7052
#6 #5 #4 #3 #2 #1 #0
NMI
[Data type] Bit axis
NMIx Always set to 1.
For the rotary axis used for torch turning control, be sure to set this bit to 1.
#7
15625
#6 #5 #4 #3
CNZ
#2 #1 #0
[Data type] Bit
CNZ In normal direction control and torch turning control, the orientation of
the C–axis is determined as follows:
0 : The conventional specification is followed.
1 : When the normal direction control or torch turning control mode is
entered, the angle of the C–axis is set so that the C–axis is in the
normal direction.
