3. MANUAL OPERATION
Bit 0 (ZPR) of parameter No. 1201 is used for automatically setting the
coordinate system. When ZPR is set, the coordinate system is
automatically determined when manual reference position return is
When a, b and g are set in parameter 1250, the workpiece coordinate
system is determined so that reference point the tip of the reference nozzle
is X= a, Y = b, Z = g when reference position return is performed. This
has the same effect as specifying the following command for reference
However, when options of the workpiece coordinate system is selected,
it is not able to use.
Once the REFERENCE POSITION RETURN COMPLETION LED
lights at the completion of reference position return, the nozzle does not
move unless the REFERENCE POSITION RETURN switch is turned
The REFERENCE POSITION RETURN COMPLETION LED is
extinguished by either of the following operations:
– Moving from the reference position.
– Entering an emergency stop state.
For the distance (Not in the deceleration condition) to return the nozzle
to the reference position, refer to the manual issued by the machine tool
D Automatically setting the
D Moving the tool again
D Reference position return
D The distance to return to
