Tool offset value output
The file (tool offset value) in the CNC memory can be output to the host
computer.
1 Place the CNC in the EDIT mode.
2 Press the function key
OFFSET
SETTING
.
3 Press the continuous menu key at the right end of the soft key display.
4 Press the [OFFSET] soft key. The tool compensation screen appears.
5 Press the [(OPRT)] soft key.
6 Press the continuous menu key at the right end of the soft key display.
7 Press the [PUNCH] soft key.
8 Press the [EXEC] soft key.
9 During output, “OUTPUT” blinks in the lower–right corner of the
screen.
The fixed file name TOOLOFS is used.
Refer to the operator’s manual of each CNC.
Workpiece origin offset value input
The file (workpiece origin offset value) on the host computer can be input
to the CNC memory.
1 Place the CNC in the EDIT mode.
2 Press the function key
OFFSET
SETTING
.
3 Press the continuous menu key at the right end of the soft key display.
4 Press the [WORK] soft key. The workpiece coordinate system setting
screen appears.
5 Press the [(OPRT)] soft key.
6 Press the continuous menu key at the right end of the soft key display.
7 Press the [READ] soft key.
8 Press the [EXEC] soft key.
9 During input, “INPUT” blinks in the lower–right corner of the screen.
The fixed file name WORKOFS is used.
Refer to the operator’s manual of each CNC.
