OPERATIONB–63664EN/02 8. DATA INPUT/OUTPUT
621
Workpiece origin offset value output
The file (workpiece origin offset value) in the CNC memory can be output
to the host computer.
1 Place the CNC in the EDIT mode.
2 Press the function key
OFFSET
SETTING
.
3 Press the continuous menu key at the right end of the soft key display.
4 Press the [WORK] soft key. The workpiece coordinate system setting
screen appears.
5 Press the [(OPRT)] soft key.
6 Press the continuous menu key at the right end of the soft key display.
7 Press the [PUNCH] soft key.
8 Press the [EXEC] soft key.
9 During output, “OUTPUT” blinks in the lower–right corner of the
screen.
The fixed file name WORKOFS is used.
Refer to the operator’s manual of each CNC.
Pitch error compensation input
The file (pitch error compensation) on the host computer can be input to
the CNC memory.
1 Place the CNC in the EDIT mode.
2 Press the function key
SYSTEM
.
3 Press the continuous menu key at the right end of the soft key display.
4 Press the [PITCH] soft key. The pitch error setting screen appears.
5 Press the [(OPRT)] soft key.
6 Press the continuous menu key at the right end of the soft key display.
7 Press the [READ] soft key.
8 Press the [EXEC] soft key.
9 During input, “INPUT” blinks in the lower–right corner of the screen.
The fixed file name PITCH is used.
Refer to the operator’s manual of each CNC.
Procedure
File name
File format, restrictions
Procedure
File name
File format, restrictions
