Pitch error compensation output
The file (pitch error compensation) in the CNC memory can be output to
the host computer.
1 Place the CNC in the EDIT mode.
2 Press the function key
SYSTEM
.
3 Press the continuous menu key at the right end of the soft key display.
4 Press the [PITCH] soft key. The pitch error setting screen appears.
5 Press the [(OPRT)] soft key.
6 Press the continuous menu key at the right end of the soft key display.
7 Press the [PUNCH] soft key.
8 Press the [EXEC] soft key.
9 During output, “OUTPUT” blinks in the lower–right corner of the
screen.
The fixed file name PITCH is used.
Refer to the operator’s manual of each CNC.
M code group input
The file (M code group) on the host computer can be input to the CNC
memory.
1 Place the CNC in the EDIT mode.
2 Press the function key
SYSTEM
.
3 Press the continuous menu key at the right end of the soft key display.
4 Press the [M–CODE] soft key. The M code group setting screen
appears.
5 Press the [(OPRT)] soft key.
6 Press the continuous menu key at the right end of the soft key display.
7 Press the [READ] soft key.
8 Press the [EXEC] soft key.
9 During input, “INPUT” blinks in the lower–right corner of the screen.
The fixed file name M–CODE is used.
Refer to the operator’s manual of each CNC.
