OPERATION9. EDITING PROGRAMS B–63664EN/02
Sequence number search operation is usually used to search for a
sequence number in the middle of a program so that execution can be
started or restarted at the block of the sequence number.
Example) Sequence number 02346 in a program (O0002) is
N01234 X100.0 Z100.0 ;
N02345 X20.0 Z20.0 ;
N02346 X10.0 Y10.0 ;
number is found.
This section is
searched starting at
(Search operation is
performed only within a
Procedure for sequence number search
1 Select MEMORY mode.
3 ⋅ If the program contains a sequence number to be searched for,
perform the operations 4 to 7 below.
⋅ If the program does not contain a sequence number to be searched
for,select the program number of the program that contains the
sequence number to be searched for.
4 Key in address
5 Key in a sequence number to be searched for.
6 Press the
[N SRH] key.
7 Upon completion of search operation, the sequence number searched
for is displayed in the upper–right corner of the screen.
If the specified sequence number is not found in the program currently
selected, P/S alarm No. 060 occurs.
