OPERATION10. CREATING PROGRAMS
B–63664EN/02
658
1 Set the setting data SEQUENCE NO. to 1 (on). (The incremental value
parameter (No. 3216) is assumed to be “1”.)
2 Select the
TEACH IN HANDLE mode.
3 Make positioning at position
P0 by the manual pulse generator.
4 Select the program screen.
5 Enter program number O1234 as follows:
O
1
2 3
4
INSERT
This operation registers program number O1234 in memory.
Next, press the following keys:
EOB
INSERT
An EOB (;) is entered after program number O1234. Because no
number is specified after N, sequence numbers are automatically
inserted for N0 and the first block (N1) is registered in memory.
6 Enter the P0 machine position for data of the first block as follows:
G 9 2
INSERT
X
INSERT
Y
INSERT
Z
INSERT EOB INSERT
This operation registers G92X10000Y0Z10000; in memory. The
automatic sequence number insertion function registers N2 of the
second block in memory.
7 Position the tool at
P1 with the manual pulse generator.
8 Enter the
P1 machine position for data of the second block as follows:
G
0 0
INSERT
G 9
0
X
INSERT
Y
INSERT EOB INSERT
This operation registers G00G90X3025Z23723; in memory. The
automatic sequence number insertion function registers N3 of the third
block in memory.
9 Position the tool at
P2 with the manual pulse generator.
10 Enter the
P2 machine position for data of the third block as follows:
G
0
1
INSERT
Z
INSERT
F 3
0 0
INSERT EOB INSERT
This operation registers G01Z –325F300; in memory.
The automatic sequence number insertion function registers N4 of the
fourth block in memory.
11 Register M02; in memory as follows:
M 0
2
INSERT EOB INSERT
N5 indicating the fifth block is stored in memory using the automatic
sequence number insertion function. Press the
DELETE
key to delete it.
This completes the registration of the sample program.
