OPERATION

B–63664EN/02

14. SCREEN HARDCOPY

761

SCREEN HARDCOPY

The screen hardcopy function outputs the information displayed on the

CNC screen as 640*480–dot bitmap data. This function makes it possible

to produce a hard copy of a still image displayed on the CNC.

The created bitmap data can be displayed on a PC.

Screen Hardcopy Procedure

1 Check the parameter settings. To use the screen hardcopy function,

set bit 7 of parameter 3301 to 1 and parameter 20 (I/O channel

selection) to 4 (memory card I/F). Set other relative parameters (bits

0, 2, and 3 of parameter 3301) as needed. In a multipath system, set

the parameters for each path.

2 Insert a memory card.

3 To start the function, set hardcopy start signal HDREQ (G67#7) to 1.

Alternatively, hold down the [SHIFT] key for five seconds.

4 To end the function, press the [CAN] key. Alternatively, set hard

copy stop signal HDABT (G67#6) to 1.

5 While the screen hardcopy operation is in progress, the hardcopy in

progress signal (F061#3) is tied to 1. For several tens of seconds (or

several seconds, for a monochrome LCD) before the hardcopy

operation ends, the screen image stands still.

6 When the screen hardcopy operation is completed, the hardcopy in

progress signal (F061#3) goes 0.

While the screen hardcopy operation is in progress, the screen image

keeps still. This means that the clock displayed on the screen indicates

the beginning and end of the operation. When the clock stops counting

seconds, the hard copy operation starts. The clock resumes counting

seconds when the screen hard copy operation ends.
