APPENDIXG. ALARM LIST
B–63664EN/02
844
Number ContentsMessage
033 NO SOLUTION AT CRC A point of intersection cannot be determined for cutter compensation C.
Modify the program.
034 NO CIRC ALLOWED IN ST–UP /EXT
BLK
The start up or cancel was going to be performed in the G02 or G03
mode in cutter compensation C. Modify the program.
036 CAN NOT COMMANDED G31 Skip cutting (G31) was specified in cutter compensation mode.
Modify the program.
037 CAN NOT CHANGE PLANE IN CRC The plane selected by using G17, G18 or G19 is changed in cutter com-
pensation C mode. Modify the program.
038 INTERFERENCE IN CIRCULAR
BLOCK
Overcutting will occur in cutter compensation C because the arc start
point or end point coincides with the arc center.
Modify the program.
041 INTERFERENCE IN CRC Overcutting will occur in cutter compensation C. Two or more blocks
are consecutively specified in which functions such as the auxiliary
function and dwell functions are performed without movement in the cut-
ter compensation mode. Modify the program.
042 G45/G48 NOT ALLOWED IN CRC Tool offset (G45 to G48) is commanded in cutter compensation. Modify
the program.
046 ILLEGAL REFERENCE RETURN
COMMAND
Other than P2, P3 and P4 are commanded for 2nd, 3rd and 4th refer-
ence position return command.
051 MISSING MOVE AFTER CHF/CNR Improper movement or the move distance was specified in the block
next to the chamfering or corner R block.
Modify the program.
052 CODE IS NOT G01 AFTER CHF/CNR The block next to the chamfering or corner R block is not G01,G02,or
G03. Modify the program.
053 TOO MANY ADDRESS COMMANDS For systems without the arbitary angle chamfering or corner R cutting,
a comma was specified. For systems with this feature, a comma was fol-
lowed by something other than R or C Correct the program.
055 MISSING MOVE VALUE IN CHF/CNR In the arbitrary angle chamfering or corner R block, the move distance
is less than chamfer or corner R amount.
Alternatively, an arc end–point command has been omitted.
058 END POINT NOT FOUND In a arbitrary angle chamfering or corner R cutting block, a specified axis
is not in the selected plane. Correct the program.
059 PROGRAM NUMBER NOT FOUND In an external program number search, a specified program number
was not found. Otherwise, a program specified for searching is being
edited in background processing. Check the program number and ex-
ternal signal. Or discontinue the background eiting.
060 SEQUENCE NUMBER NOT FOUND Commanded sequence number was not found in the sequence number
search. Check the sequence number.
070 NO PROGRAM SPACE IN MEMORY The memory area is insufficient.
Delete any unnecessary programs, then retry.
071 DATA NOT FOUND The address to be searched was not found. Or the program with speci-
fied program number was not found in program number search.
Check the data.
072 TOO MANY PROGRAMS The number of programs to be stored exceeded 125 (basic), 200 (op-
tion), 400 (option), or 1000 (option). Delete unnecessary programs and
execute program registeration again.
073 PROGRAM NUMBER ALREADY IN
USE
The commanded program number has already been used.
Change the program number or delete unnecessary programs and
execute program registeration again.
074 ILLEGAL PROGRAM NUMBER The program number is other than 1 to 9999.
Modify the program number.
075 PROTECT An attempt was made to register a program whose number was pro-
tected.
076 ADDRESS P NOT DEFINED Address P (program number) was not commanded in the block which
includes an M98, G65, or G66 command. Modify the program.
077 SUB PROGRAM NESTING ERROR The subprogram was called in five folds. Modify the program.
