PROGRAMMING

B–63664EN/02

5. FEED FUNCTIONS

The machining angle is compared with the angle specified in parameter

(No. 1740) for movements on the selected plane only. Machining

feedrates are compared with that specified in parameter (No. 1741) for

movement along the first and second axes on the selected plane only. This

means, when movement occurs along three or more axes, only that

movement along the first and second axes on the selected plane is

considered.

Corner roundness is determined by the angle and feedrate specified in

parameter (Nos. 1740 and 1741). To always make a sharp corner, set

the angle to zero and the feedrate to 180000 (equivalent to 180

degrees).

When G90 (exact stop) is specified, exact stop is performed irrespective

of the angle and feedrate specified in parameter (Nos. 1740 and 1741).

Those parameters related to automatic corner deceleration in advanced

preview control mode are shown below.

Parameter description

Normal

mode

Advanced

preview

control mode

Switching the methods for automatic corner

deceleration

No.1602#4 No.1602#4

Lower limit of feedrate in automatic corner

deceleration based on the angle

No.1777 No.1778

Limit angle in corner deceleration based on

the angle

No.1740 No.1779

This function cannot be enabled for a single block or during dry run.

D Selected plane

D Corner roundness

D Exact stop

D Advanced preview

control

Limitations
