1. ABOUT FA SYSTEM FOR PC B-75044EN/02
-6-
Functions of NC PROGRAM MANAGEMENT (A08B-9510-J511)
(1) For DNC1 or DNC2
NC PROGRAM MANAGEMENT can handle the following functions by
operating a computer.
K A computer can download an NC program to an NC memory.
K A computer can upload an NC program from an NC memory.
K NC PROGRAM MANAGEMENT can display the list of NC
programs saved in the NC memory.
K NC PROGRAM MANAGEMENT can delete the NC program
saved in the NC memory.
The following functions can be handled by operating the CRT/MDI on
an NC.
K An NC can read an NC program from a computer.
K An NC can punch an NC program to a computer.
K An NC can call an NC program saved in a computer for DNC
operation.
(2) For Reader/Puncher
The following functions can be handled by operating the CRT/MDI on
an NC.
K An NC can read an NC program from a computer.
K An NC can punch an NC program to a computer.
K An NC can display the list of NC programs saved in a computer.
K An NC can delete an NC program saved in a computer.
K An NC can call an NC program saved in a computer for DNC
operation.
(3) For DNC1/Ethernet
NC PROGRAM MANAGEMENT can handle the following functions by
operating a computer:
K A computer can download an NC program to NC memory.
K A computer can upload an NC program from NC memory.
K NC PROGRAM MANAGEMENT can display the list of NC
programs saved in the NC memory.
K NC PROGRAM MANAGEMENT can delete the NC program
saved in NC memory.
NOTE
When you uses the Reader/Puncher for some old types of NCs, it is
impossible to use several above functions, or it is necessary to add NC
optional parameters.
NOTE
DNC1/Ethernet communication does not allow download or upload by
CRT/MDI operations on the NC. (scheduled to be supported)
