8. EMERGENCY STOP SIGNAL

294

EMERGENCY STOP SIGNAL

We recommend appropriate use of the emergency stop signal when

designing a safe machine tool.

The emergency stop signal is for stopping the machine tool in an

emergency, and is input to the CNC controller, servo amplifier and spindle

amplifier. Generally, B–contact pushbutton switches are used for the

emergency stop signal.

When the emergency stop signal (*ESP) contact is closed, the CNC

controller is set to an emergency stop canceled state, and the servo

amplifier and spindle motor can be controlled and operated.

When the emergency stop signal (*ESP) contact is open, the CNC

controller is reset to an emergency stop state, and the servo amplifier and

spindle motor are decelerated and stopped.

In the case of the servo motor, the drive power supply of the servo

amplifier is turned OFF to activate a dynamic brake and stop servo motor

operation. Since gravity causes the servo motor used for the gravity shaft

to continue operation, you must consider using a servo motor with a

brake.

In the case of the spindle motor, if the drive power supply of the spindle

amplifier is suddenly turned OFF turning spindle operation, inertia causes

the spindle to continue operation, which is more dangerous. The spindle

motor must be controlled in such a way that deceleration and stopping of

spindle motor operation is confirmed before its drive power supply is

turned OFF when the emergency stop signal (*ESP) contact has become

open.

The above have been taken into consideration in FANUC’s α series of

control amplifiers. On these control amplifiers, input the emergency stop

signal to the power supply module (PSM). Since the drive power supply

MCC control signal is output from the PSM, use this signal to control

ON/OFF switching of the drive power supply that is input to the power

supply module.

Detection of overtravel by the software limit function is included in the

basic specifications of this CNC controller, and limit switches for regular

detection of overtravel are not required. However, if a malfunction in the

servo feedback system causes the machine tool to move beyond the

software limits, provide stroke end limit switches so that the emergency

stop signal functions to stop the machine tool.

Figure 8 shows a example of how the emergency stop signal is connected

when this CNC controller and an α series control amplifier are used.
