Spindle parameter table [SPINDLE HRV Control] (2005.02.17)
MTB:
Spindle motor: A06B-1675-B100#Z311
α112L/15000i
B
BZi sensor 256 teeth
Spindle amplifier: A06B-6111-H030#H550
SPM-30i (TYPE A)
For FS16i, FS15i
A06B-6111-H030#H570
SPM-30i (TYPE A)
For FS30i
Low speed range High speed range
Parameter No. 15/18.5 kW Parameter No. 18.5/22 kW
FS15i FS16i FS30i
1500/3500
min
-1
FS15i FS16i FS30i
5000/15000
min
-1
3001 4001 4001
00000001
3002 4002 4002
00000001
3003 4003 4003
00000000
3004 4004 4004
00000000
3006 4006 4006
00000000
3007 4007 4007
00000000
3008 4008 4008
00010000
3009 4009 4009
00000000
3010 4010 4010
00000001
3011 4011 4011
00001010
3012 4012 4012
10000010
3013 4013 4013
01010000
3019 4019 4019
00000100
3020 4020 4020
15000
3023 4023 4023
233
3156 4156 4156
0
3039 4039 4039
0
3166 4166 4166
70
3080 4080 4080
7760
3138 4138 4138
1295
3100 4100 4100
5000
3139 4139 4139
95
3101 4101 4101
75
3140 4140 4140
2184
3102 4102 4102
5755
3141 4141 4141
0
3103 4103 4103
0
3142 4142 4142
3000
3104 4104 4104
1000
3105 4105 4105
0
3143 4143 4143
3000
3106 4106 4106
1000
3107 4107 4107
0
3144 4144 4144
0
3108 4108 4108
0
3145 4145 4145
25
3109 4109 4109
25
3146 4146 4146
1886
3110 4110 4110
1006
3147 4147 4147
550
3111 4111 4111
288
3148 4148 4148
200
3112 4112 4112
200
3149 4149 4149
876
3113 4113 4113
731
3150 4150 4150
0
3114 4114 4114
0
3151 4151 4151
100
3115 4115 4115
100
3152 4152 4152
10197
3116 4116 4116
8548
3153 4153 4153
90
3117 4117 4117
90
3154 4154 4154
100
3118 4118 4118
100
3165 4165 4165
11
3119 4119 4119
13
3120 4120 4120
0
3155 4155 4155
0
3124 4124 4124
0
3093 4093 4093
148
3127 4127 4127
143
3158 4158 4158
110
3128 4128 4128
105
3159 4159 4159
0
3129 4129 4129
0
3161 4161 4161
25700
3130 4130 4130
25700
3134 4134 4134
180
3169 4169 4169
0
Maximum power at acceleration (for selecting PSM): 29.4 kW
[Parameter setting procedure]
(1) Load parameters
automatically with the model
code "400".
Note) If you don’t want to
initialize adjusted
parameters, you should not
load parameters
automatically.
(2) Change parameters
manually according to the
table.
(3) Power off/on to activate the
SPINDLE HRV parameters
surely.
A
A-225281/01
