FANUC Series 30i/31i/32i-A Specification Change of The Shape of FAN Unit Additional Manual Page 2
Additional Manual
M.NAKAMURA
CUST.
TITLE
FANUC Series 30i/31i/32i-A Specification
Change of The Shape of FAN Unit
SHEET
A
-65566E
FANUC LTD
DRAW. NO.
DATA DESIG.
01
05.09.27 K.KUSAKABE
DESCRIPTION
1/1
FANUC Series 30i/31i/32i-A Specification Change of The Shape of FAN Unit
Contents
The shape of FAN unit for FS30i/31i/32i-A stand-alone basic unit (2 slots) is changed in order
to improve the efficiency of radiation of heat.
Note that the shape of FAN unit is changed as follows.
From September 2005, the new FAN unit is applied
.
Current FAN unit
New FAN unit
FAN unit
Stand-alone basic unit (2 slots)
2mm
62mm 87mm
