Improvement of External Workpiece Number Search Supplement to Manual Page 1
Supplement to Manual
Edit
1
/
4
Data Si
g
nature
Descri
p
tion
FANUC Series 16/18-MB/TB/MC/TC
FANUC Series 16i/18i-MA/TA
Improvement of external workpiece number search
A-60216EN
Drawing No.
Title
Page
Contents
1.OUTLINE ………………………………………………. 2
2.DETAILS ………………………………………………… 2
3.SIGNALS ………………………………………………… 2
4.PARAMETERS ………………………………………….. 4
5.NOTES .......……………………………………………… 4
FANUC Series 16/18-MB/TB/MC/TC
FANUC Series 16i/18i-MA/TA
Improvement of External workpiece
number search
Specifications
1999/05/20 N.Hatanaka
SPEC01/057
Contents Summary of Improvement of External Workpiece Number Search Supplement to Manual
- Page 1FANUC Series 16/18-MB/TB/MC/TC FANUC Series 16i/18i-MA/TA Improvement of External workpiece number search Specifications Contents 1.OUTLINE ………………………………………………. 2 2.DETAILS ………………………………………………… 2 3.SIGNALS ………………………………………………… 2 4.PARAMETERS ………………………………………….. 4 5.NOTES .......……………………………………………… 4 SPEC
- Page 21. OUTLINE External workpiece number search function is improved in following 2 points. 1. Workpiece number range is extended from 1 to 9999. 2. Workpiece number search start signal is added. 2. DETAILS 1. In usual, workpiece range from 1 to 31 is available by using workpiece number search signals(P
- Page 3Workpiece number 0 is used for special designation "no search", Thus a workpiece number ranges from 1 to 9999 are available. NOTE Workpiece numbers 10000 to 16383 are not available even if program number O with 8 digits function is specified. [Signal address] Address #7 #6 #5 #4 #3 #2 #1 #0 G0024 EP
- Page 44. PARAMETERS Number #7 #6 #5 #4 #3 #2 #1 #0 3006 EPS EPN [Data type] Bit EPN Workpiece number search signals are assigned to: 0: PN1,PN2,PN4,PN8, and PN16. 1: EPN0 to EPN13. EPS When a program is searched using the workpiece number search function, it is started by: 0: Automatic operation start sig
