Change of the setting of short plug for PSM Additional Manual Page 2
Additional Manual
EDIT.
01 99.12.20
DATE
Makita
DESCRIPTION
DESIG.
New designation
TITLE
DRAW.
No.
Change of the setting of short
plug for SERVO AMPLIFIER
ALPHA Series PSM
A-53866E-373
FANUC LTD
SHEET
1/1
Change of the setting of the short plug S1, S2
for SERVO AMPLIFIER ALPHA Series PSM
[Outline]
We will change the setting of the short plug S1, S2 for SERVO AMPLIFIER ALPHA
Series PSM-5.5, PSM-11.
The function of the short plug is the changing the timing for regeneration.
In the case of changing the setting, the distortion of input voltage and noise at the
regeneration are suppressed .
[Applied Unit]
A06B-6077-H106, A06B-6077-H106#BM
A06B-6077-H111, A06B-6077-H111#BM
[Contents of change]
We will change the setting of the short plug S1, S2
Short plug Current setting New setting
S1 SHORT SHORT
S2 SHORT OPEN
[Applied time]
January 2000 is scheduled.
