FANUC Series 30i/31i-MODEL A
Specifications for Speed Command Extension
in Least Input Increments D and E
#7 #6 #5 #4 #3 #2 #1 #0
2282 ISE64
[Input type] Parameter input
[Data type] Bit axis
# 3 ISE64 The speed limitation of feed forward(Parameter No.2005#1(FEED)=1):
0: Former specification.
1: Extended specification.
The feedrate limitation is shown in the following tables, when the feed
forward function is made to effective
IS-C IS-D IS-E
Former
Spec.
Extended
Spec.
Former
Spec.
Extended
Spec.
Former
Spec.
Extended
Spec.
Feedrate
[unit:mm/min]
100000 100000 19000 100000 1900 100000
Notes
NOTE
1 To use this function, the corresponding servo
software is required.
2 This function is included in the option for the least
input increment D(IS-D) or E(IS-E).
3 This function cannot be applied the axis of PMC
axis control.
