  2. FANUC Series 16i/18i-MB 18i-MB5 Skip function for Flexible Synchronous Control

FANUC Series 16i/18i-MB 18i-MB5 Skip function for Flexible Synchronous Control Additional Manual Page 4

Additional Manual
2004/04/03
Edit
4/5
Data Si
g
nature
Descri
p
tion
FANUC Series 16i/18i-MB, 18i-MB5
Skip function
for Flexible synchronous control Specifications
A-79507EN
Drawing No.
Title
Page
4 Signal
Please refer to ‘FS16i/18i CONNECTION MANUAL (FUNCTION) (B-
63523EN-1) 14.3.1 Skip function and 14.3.2 High-speed Skip Signal’.
5 Parameter
#7 #6 #5 #4 #3 #2 #1 #0
6200 SRE HSS
[Data type] Bit
HSS 0: The skip function does not use high-speed skip signals.
1: The skip function uses high-speed skip signals.
SRE When a high-speed skip signal is used:
0: The signal is considered to be input at the rising edge (0 to 1).
1: The signal is considered to be input at the falling edge (1 to 0)
#7 #6 #5 #4 #3 #2 #1 #0
6208 9S8 9S7 9S6 9S5 9S4 9S3 9S2 9S1
[Data type] Bit
9S1 ~ 9S8 Specify which high-speed skip signal to be enabled for the G31.8 command.
The bits correspond to signals as follows:
9S1 ----- HDI0
9S2 ----- HDI1
9S3 ----- HDI2
9S4 ----- HDI3
9S5 ----- HDI4
9S6 ----- HDI5
9S7 ----- HDI6
9S8 ----- HDI7
Set each bit as follows:
0: The corresponding skip signal is invalid.
1: The corresponding skip signal is valid.
6220 Period during which input is ignored for high-speed skip signal
[Data type] Byte
[Unit of data] 8 ms
[Valid Data range] 3 ~ 127 ( x 8ms )
If a value that falls outside this range is specified, 3 (x 8ms) is assumed.
This parameter specifies the period that must elapse between a high-speed
skip signal being input and input of the next high-speed skip signal being
enabled. This parameter is used to ignore chattering in skip signals.
