Update of Servo Software 90B0 for FS15i, FS16i and FS18i (with 320C5410 DSP) Supplement to Manual Page 4

Supplement to Manual
3/11
Descri
p
tion
Design.
DateEd
01.04.20




Taka
y
ama
Newly designed
Notice of the update of Digital
Servo Software 90B0 series
A-62449E-084
FANUC LTD
Attached 1. Parameter table for
α
αα
α
i
series servo motors
Standard parameters for
α
i
series servo motors are added to parameter table
(See following
Tables 1-1
to
Table 1-4
)

Please set suitable motor types No. for the control ,HRV1 or HRV2/HRV3.
Because
α
i series servo motor types No. of HRV1 control is different from that of
HRV2/HRV3 control.
Types No. for HRV1 control : 152 to 222
Types No. for HRV2/HRV3 control : 252 to 322
New motors are
α
1/5000
i
,
α
2/5000
i
,
α
M2/5000
i
,
α
M3/5000
i
,
α
C4/3000
i
,
α
4/4000
i
,
α
C8/2000
i
,
α
8/3000
i
,
α
M8/4000
i
,
α
M12/4000
i
,
α
C12/2000
i
,
α
12/3000
i
,
α
C22/2000
i
,
α
22/3000
i
,
α
C30/1500
i
,
α
30/3000
i
,
α
40/3000
i
,
α
M22/4000
i
,
α
M30/4000
i
,
α
M40/4000
i

Please set following parameters too when HRV3-High speed HRV control is used.
#7 #6 #5 #4 #3 #2 #1 #0
Series15
i
1707 HRV3AX
Series16
i
2013
HRV3AX (#0)
1: Enables High speed HRV control
#7 #6 #5 #4 #3 #2 #1 #0
Series15
i
1742 VGCCR
Series16
i
2202
VGCCR (#1)
1: Enables the cutting feed/rapid traverse switchable velocity loop gain function.
Series15
i
2747 Current loop gain override at High speed HRV control (%)
Series16
i
2334
[setting value]
150
Series15
i
1788 Velocity loop gain override at High speed HRV control (%)
Series16
i
2165
[setting value]
(tuned value)
See FANUC AC SERVO MOTOR
i
series Parameter manual B-65270/01
about High speed HRV control.
