FANUC Series 16i /18i /21i Additional Manual Page 2
Additional Manual
1. General
This is the function that enables feed-forward function or FAD function (fine
acceleration / deceleration function) by using PMC signals.
2. Specification
When the signal FDFCGx<G384> is set to 1, feed-forward or FAD function
can be controlled by the signal FDFONx<G385>.
In case FDFCGx<G384> is 1, feed-forward or FAD function is enabled when
FDFONx<G385> is 1, and it is disabled when FDFONx<G385> is 0.
2
/
4
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
Dec.13.2004
Sheet
M.Itou
FANUC Series 16i /18i /21 i – MB/TB
Feed-forward / FAD function enable/disable signal
Specification
A-79902E
Contents Summary of FANUC Series 16i /18i /21i Additional Manual
- Page 1FANUC Series 16i /18i /21i –MB/TB Feed-forward / FAD function enable / disable signal Specification - Contents - 1 GENERAL.........................................................................................................................................................2 2 SPECIFICATION........
- Page 21. General This is the function that enables feed-forward function or FAD function (fine acceleration / deceleration function) by using PMC signals. 2. Specification When the signal FDFCGx
is set to 1, feed-forward or FAD function can be controlled by the signal FDFONx . In case FDFCGx - Page 33. Signals Feed-forward / FAD control change signal FDFCG1~8
- Page 44. References - FANUC AC SERVO MOTER alpha i series PARAMETER MANUAL (B-65270EN) - FANUC AC SPINDLE MOTER alpha i series PARAMETER MANUAL (B-65280EN) FANUC Series 16i /18i /21 i – MB/TB Feed-forward / FAD function enable/disable signal Title Specification Draw A-79902E No. Edit Date Design Descripti
- Page 33. Signals Feed-forward / FAD control change signal FDFCG1~8
