FANUC Series 30i/31i/32i-MODEL A M Code Protection Function, Specifications Additional Manual Page 6

Additional Manual
A-90371E/01
Title
Draw
No.
Ed. Date Design Description
Date Dec.01.’05 Design. Apprv.
6/ 7
page
FANUC Series 30i/31i/32i -MODEL A
M code protection function
specification
s
xx11
First M code (for first range)
xx13
First M code (for second range)
xx15
First M code (for third range)
[Input type] Parameter input
[Data type] 2-word path
[Valid data range] 3 to 99999999 (excluding 30, 98 and 99)
xx12
Number of M code (for first range)
xx14
Number of M code (for second range)
xx16
Number of M code (for third range)
[Input type] Parameter input
[Data type] Word path
[Valid data range] 1 to 999
The first M code and number can be set for the protected M codes.
You can set maximum 3 of range of the protected M codes. This
setting is invalid when either the first M code or the number of M
code is invalid data range.
Setting example)
First group Second group
Third group
M code
No.xx11＝100
No.xx13＝150 No.xx15＝900
Number
No.xx12＝10 No.xx14＝5 No.xx16＝30
Protected
M code
M100 to M109
M150 to M154 M900 to M929
Note
Please set 0 into the first M code and number of M
code when you do not use the range of M code.
