Series 16i/18i/21i Additional Manual Page 1

Additional Manual
FANUC Series 16i/18i/21i–MB/TB
FANUC Series 18i–MB5
Each axis workpiece coordinate system preset signal
Specifications
−contents−
1 GENERAL ........................................................................................................................................................ 2
2 PARAMETER ................................................................................................................................................... 2
3 SIGNAL............................................................................................................................................................. 2
4 NOTE ................................................................................................................................................................ 3
A-79104E
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/18i/21i –MB/TB, 18i –MB5
Each axis workpiece coordinate system preset
signal Specifications
2004.03.26
1/3
