FS 16i Additional Manual Page 4

Additional Manual
2002/03/20 T.Horie
A-78672EN
FANUC Series 16i-MB
Jerk Control Specifications
Title
Drawing No.
Page
Descri
p
tionDate Edit
3/15
1.1 Jerk Control
Overview
AI contouring control (AICC) or AI nano contouring control
(AI nanoCC) or AI High Precision Contour control (AI-HPCC)
or AI Nano High Precision Contour control (AI-nanoHPCC),
which are high-speed, high-precision machine functions,
perform speed control in such a way that the rate of change of
acceleration (jerk) will be smooth.
As a result, vibration and shocks on the machine are reduced,
leading to machining at higher precision.
There are two types of jerk control functions as described
below.
<1> Speed control based on changes to acceleration for each
axis
Speed control for portions where there is a large change
to acceleration, for example, a portion where a specified
shape changes from a straight line to a curved line, is
performed using look-ahead acceleration/deceleration
before interpolation by obtaining a feed rate that can
keep a change to acceleration for each axis from
exceeding their permissible acceleration change level.
As a result, vibration in a servo section where there can
be a large change to acceleration is suppressed, leading
to an improved precision for cut surfaces.
<2> Look-ahead smooth bell-shaped
acceleration/deceleration before interpolation
Look-ahead bell-shaped acceleration/deceleration before
interpolation performs control in such a way that
tangential changes to acceleration in the acceleration
change time will be smooth.
As a result, ordinary bell-shaped
acceleration/deceleration can become smoother, leading
to a reduction in shocks to the machine at
acceleration/deceleration.
If the bell-shaped acceleration/deceleration is specified
as an acceleration/deceleration type for the following
functions performed in acceleration/deceleration before
interpolation, the same effect as stated above can be
achieved because this function makes changes to
acceleration smoother.
- Acceleration/deceleration before interpolation for linear
rapid traverse
- Optimum-torque acceleration/deceleration (only AI High
Precision Contour control (AI-HPCC) or AI Nano High
Precision Contour control (AI-nanoHPCC))
