Disabling_Fine_Acc_Dec_during_Cs-contouring_mode Additional Manual Page 3

Additional Manual
Ed.
App
rovalChar
g
e
page


 


3
/3
Date
2000.08.25
Descri
p
tion
Draw u
p
FS16i/18i/21i-MA/TA
Disabling Fine Acc./Dec. during Cs-contouring mode
Specifications
A-78232E
•
Signal
Fine acc./dec. function can be disabled during Cs-contouring mode for the servo axis selected by the PMC signal CDFn<G127>(n = 1
–8).
[Classification] Input signal
[Function] During Cs-contouring mode, Fine acc./dec. function is:
0: Not disabled
1: Disabled.
* Fine acc./dec. function is disabled immediately when the signal is turned 1. Therefore, the signal manipulation must be done while
the axis concerned stops. Otherwise, it may have a shock.
* The signal is effective when the parameter CSL(No.3710#6) is 0 during Cs-contouring mode.
* In multi-path system when the parameters CSL(No.3710#6) and CAL(No.3712#0) are both 1, Fine acc./dec. function is disabled for
all the servo axes specified in the parameters No.39n0 to interpolate with Cs axis on all paths regardless of the path in Cs-contouring
mode.
•
Signal address
#7 #6 #5 #4 #3 #2 #1 #0
G0127 CDF8 CDF7 CDF6 CDF5 CDF4 CDF3 CDF2 CDF1
•
Note
Fine acc./dec. function is effective when the parameter FAD(No.2007#6) is 1.
