Additional Manual
About the application of IEC60825-1, Amendment 2:2001 of Laser C series
1. OUTLINE
The laser equipment (oscillator, processing machine, applied equipment) for Europe should
agree with the safety standard concerning the laser radiation, IEC60825-1, Amendment 2:2001
from January, 2004.
Therefore, FANUC changes the class of visible laser and the danger label for access panel
about our laser oscillator to conform to this Amendment from manufacturing in December, 2003.
2. OBJECT
For Europe of laser C1000-E, C2000-E, C4000-E, C5000-E, C6000-E
3. CONTENTS
3.1 Class indication label (Refer to Fig.1.)
- The class of visible laser is changed from 3A to 3R.
- The application standard is changed as follows.
“IEC60825-1:1993 + A2:2001”
3.2 Danger label for access panel (Refer to Fig.2 and Fig.3.)
- “Class 4” is added to this label.
4. APPLICATION
From FANUC manufacturing in December, 2003 of the following table
There is a charge for exchanging if you need to change the labels of the laser oscillator with old
labels.
[Applied when factory shipped]
MODEL O/S No. Serial No.
C1000-E H10417 L03Z10915
C1000-E H10418 L03Z10916
C1000-E H10419 L03Z10917
C1000-E H10420 L03Z10918
C1000-E H10421 L03Z10919
C1000-E H10422 L03Z10920
C2000-E Y92271 L03Z20844
C2000-E Y92272 L03Z20845
C2000-E A28187 L03Z20846
C4000-E Y92251 L03Z40907
C4000-E Y92252 L03Z40908
C4000-E Y92253 L03Z40909
C4000-E Y92269 L03Z40910
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
001/2
DESCRIPTIONDESIG.DATE
01 03.12.24 E.K. Newly
About the application of IEC60825-1,
Amendment 2:2001 of LASER C series
A-81053E-062
