4. DESCRIPTION OF PARAMETERS

B–63610EN/01

232

NOTE

1 The M code is judged to be 29 (M29) when “0” is set.

2 To use an M code whose number is greater than 255, Specify

the code number with parameter No.5212.

5211 Override value during rigid tapping extraction

[Data type] Byte

[Unit of data] 1 % or 10 %

[Valid data range] 0 to 200

The parameter sets the override value during rigid tapping extraction.

NOTE

The override value is valid when DOV in parameter No.5200

#4 is “1”.

When OVU (bit 3 of parameter No.5201) is 1, the unit of set data

is 10%. An override of up to 200% can be applied to extraction.

5212 M code that specifies a rigid tapping mode

[Data type] 2–word

[Unit of data] Integer

[Valid data range] 0 to 65535

This parameter sets the M code that specifies the rigid tapping mode.

The M code that specifies the rigid tapping mode is usually set by

parameter 5210. To use an M code whose number is greater than 255,

specify the code number with parameter 5212.

NOTE

If the setting of this parameter is 0, the M code specifying the

rigid tapping mode is determined by the setting of parameter

5210. Otherwise, it is determined by the setting of parameter

5212. The setting of parameter 5212 must always be within

the above valid range.

5213

Return or clearance in peck tapping cycle

[Data type] Word

[Unit of data]

Increment system IS–A IS–B IS–C Unit

Millimeter input 0.01 0.001 0.0001 mm

Input in incluse 0.001 0.0001 0.00001 inch

[Valid data range] 0 to 32767

This parameter sets the return or clearance in the peck tapping cycle.
