FS16i/18i/160i/180i/160is/180is-MODEL A CPU card modification Additional Manual Page 1

Additional Manual
TECHNICAL REPORT (MANUAL) NO. TMN 99/146E
Date 18 Oct., 1999
General Manager of
Hardware Laboratory
FS16i/18i/160i/180i/160is/180is-MODEL A CPU card modification
1. Communicate this report to :
Your information
○
GE Fanuc-N, GE Fanuc-E
FANUC Robotics
CINCINNATI MILACRON
○
Machine tool builder
Sales agency
End user
2. Summary for Sales Documents
FANUC modifies the CPU card for FS16i/18i/160i/180i/160is/180is-MODEL A to new one.
Please replace the old report by this one.
3. Notice
4. Attached Document
Drawing
No.
A-71211E-044 Edition 03 (1/4 ~ 4/4) : Rewrite overall
No.HLB1-99/A115
18 Oct. , 1999
Order section of issuer of issue
IDE Manager Chief
Previous page
Next page

Contents Summary of FS16i/18i/160i/180i/160is/180is-MODEL A CPU card modification Additional Manual

  • Page 1TECHNICAL REPORT (MANUAL) NO. TMN 99/146E Date 18 Oct., 1999 General Manager of Hardware Laboratory FS16i/18i/160i/180i/160is/180is-MODEL A CPU card modification 1. Communicate this report to : Your information ○ GE Fanuc-N, GE Fanuc-E FANUC Robotics CINCINNATI MILACRON ○ Machine tool builder Sales
  • Page 2Abstract FANUC modifies the CPU card for FS16i/18i/160i/180i/160is/180is-MODEL A to new one using higher speed CPU to obtain higher performance. And FANUC modifies DRAM module that is mounted on CPU card also. And you must use the system software that is adapted to the new CPU card in case you use i
  • Page 3CPU card for Sub CPU board Item Present specification New specification A02B-0236-J080 A02B-0236-J040 CPU card for A (DRAM 4MB) (A20B-3300-0050 (A20B-3300-0170 Sub CPU board +A20B-3900-0042) +A20B-3900-0132) A02B-0236-J081 A02B-0236-J041 B (DRAM 8MB) (A20B-3300-0050 (A20B-3300-0170 +A20B-3900-0041)
  • Page 43. Adapting software System software System Software No. Edition B1F1 22 or later FS16i/160i/160is-TA B1FA 01 or later FS16i/160i/160is-TA (adapting to Stand-alone type) B1F2 02 or later B0F1 23 or later FS16i/160i/160is-MA B0FA 01 or later FS16i/160i/160is-MA (adapting to Stand-alone type) B0F2 02
  • Page 5Behavior is listed below in case that software of unadaptable edition is installed in NC control. # System Behavior The screen is black out after boot software displays (1) FS16i/18i-MODEL A “ LOADING BASIC TO DRAM ”. LED status on the motherboard is as follows. Nothing is displayed on the screen. (
