Series 16i/18i-PB, Level up for Safety Zone Check, Specifications Additional Manual Page 2
Additional Manual
1. Addition of Safety Zone Check-Type A
At present, in case of “punch forbidden area“ type safety zone, the CNC issues an alarm before
movement if the punch position is in the punch forbidden area.
But the following functions are available to set the parameter No.16504#0 (SPA) =1.
The CNC issues an alarm before movement if the end of positioning command (including no
punch positioning) is in the punch forbidden area.
•
•
•
•
The CNC issues an alarm before movement if the positioning (including no punch positioning)
is commanded through the punch forbidden area.
The above cases, alarm No.4800-No.4807 are displayed.
During cutting mode and JOG mode, the tool can be entered into the punch forbidden area.
In case of the avoid operation signal ACZEXE(G232#6) =1 for workpiece holder interference
avoidance function-Type B, an avoidance motion is performed without interference alarm if the
positioning is commanded through the punch forbidden area.
2. Ignore Safety Zone Check Signal
During the signal SAFNG (G239#0) is set to “1”, the safety zone check is ignored.
3. Addition of Round Tool Zone
The safety zone check by round tool zone is available. Consequently, the punch area nearby
workpiece holder is extended.
The round tool zone is available by the parameter No.16504#1(RTZ)=1.
3.1 Definition of round tool zone
The tool areas are set to the parameter No.16517-No.16532, No.16551-No.16558.
The definition of round tool or rectangular tool is as follows.
When the tool area of X value is not “0” and Y value is “0”, it is a round tool which radius is X
value.
When the tool area of X value and Y value are not “0”, it is a rectangular tool.
