Connector Support to JN2 Connector for Brake and Fan Additional Manual Page 2

Additional Manual
A-85200E
1
Connector Support to JN2 Connector for Brake and Fan
1. Applicable connector support to JN2 connector for brake and fan of αi series
Since the outline dimensions of the strengthened JN2 connector are a little larger than
the conventional JN1 connector, the existing connector support cannot be applicable to
the elbow-type JN2 connector.
If a connector support is needed to the elbow-type JN2 connector, please use the below
new connector support.
Connector support for elbow-type JN2 connector
Specification: A06B-6114-K215#E
For the straight-type JN2 connector, the existing connector support(A06B-6114-K212#S)
is applicable as usual.
2. Specification table of connector support for brake and fan
Refer to the below table about the specification of connector support applicable to each
connector for brake and fan.
Connector for brake and fan (FANUC specification)
Applicable connector
support
Previous page
Next page

Contents Summary of Connector Support to JN2 Connector for Brake and Fan Additional Manual

  • Page 1TECHNICAL REPORT (MANUAL) No.TMS04/003E Date: Feb. 3, 2004 General Manager of Servo Laboratory Connector Support to JN2 Connector for Brake and Fan 1. Distribute this report to the destinations marked with O: O Your information O GE Fanuc-N, GE Fanuc-E Fanuc Robotics-NA, Fanuc Robotics-E CINCINNATI
  • Page 2A-85200E Connector Support to JN2 Connector for Brake and Fan 1. Applicable connector support to JN2 connector for brake and fan of αi series Since the outline dimensions of the strengthened JN2 connector are a little larger than the conventional JN1 connector, the existing connector support cannot
  • Page 3A-85200E Strengthened for brake A06B-6114-K213#S Straight (JN2) for fan A06B-6114-K214#S A06B-6114-K212#S -type Conventional for brake A06B-6114-K210#S (existing) (JN1) for fan A06B-6114-K211#S Strengthened for brake A06B-6114-K213#E A06B-6114-K215#E Elbow (JN2) for fan A06B-6114-K214#E (new) -type
  • Page 4A-85200E 3. Outline drawings Connector support for straight-type JN1 and JN2 connector : A06B-6114-K212#S 3
  • Page 5A-85200E Connector support for elbow-type JN2 connector: A06B-6114-K215#E 4
  • Page 6A-85200E Connector support for elbow-type JN1 connector: A06B-6114-K212#E 5
