Changing of specification in the processing nozzle Additional Manual Page 3
Additional Manual
TITLE
DRAW
.
No.
2/ 2
Page
FANUC LTD
DESCRIPTIONDESIGNDATE
EDIT
Changing of specification
in the
p
rocessin
g
nozzle
A-63618 E
–
550
New re
g
istration
YAMAMOTO
2000071401
Before
Specification Outer dimensions Nozzle tip Nozzle tip Remarks
specification hole diameter
After
Specification Outer dimensions Nozzle tip Nozzle tip Remarks
specification hole diameter
A04B-0850-
H300
A290-4600-
X255
φD=φ2.0
A04B-0850-
H300/D15
A04B-0850-
H300/D20
A290-4600-
X610
A290-4600-
X611
φD=φ1.5
φD=φ2.0
Equal to
A04B-0850-
H300
A04B-0850-
H300/D30
A290-4600-
X258
φD=φ3.0
A04B-0850-
H300/D40
A04B-0850-
H300/D50
A290-4600-
X372
A290-4600-
X375
φD=φ4.0
φD=φ5.0
