FS 16i/18i-MA/MB, Improvement of acc./dec. time constant setting before interpolation (AI contour control, AI nano contour control, Advanced preview control) Supplement to Manual Page 2

Supplement to Manual
1.1 Specification
The acceleration/deceleration time constant before interpolation during AI contour
control, AI nano contour control, Advanced preview control and normal mode can be
set separately for linear axis and rotary axis.
However, the axis stops once at the point between the block excluding rotary axis
command and the block including rotary axis command.
Acc/dec time constant before interpolation (Normal mode) •
•
•
For linear axis (command excluding rotary axis)
Parameter No.1630, No.1631
For rotary axis (command including rotary axis)
Parameter No.1630, No.1633 (Newly addition)
Acc/dec time constant before interpolation (AI contour control, AI nano contour
control and Advanced preview control)
For linear axis (command excluding rotary axis)
Parameter No.1770, No.1771
For rotary axis (command including rotary axis)
Parameter No.1770, No.1786 (Newly addition)
Time constant of bell-shaped acc/dec before interpolation (AI contour control, AI
nano contour control)
For linear axis (command excluding rotary axis)
Parameter No.1772
For rotary axis (command including rotary axis)
Parameter No.1787 (Newly addition)
Version
assent
end
Page
Name
No
Date
E
nd
Chan
g
es
date
FANUC Series 16i/18i-MA/MB，18i-MB5
Improvement of acc/dec time constant setting
before interpolation Specifications
2002.11.20
2/5
A-78443E
