Series 30i-MODEL A, DIAMETER AND RADIUS SETTING SWITCHING Additional Manual Page 7

Additional Manual
A-79340E
Title
Draw
No.
Ed. Date Design Description
Date Jan.06.’04 Design. Apprv.
page
FANUC Series 30i-MODEL A
DIAMETER AND RADIUS SETTING
SWITCHING
Jan.06.’04
New design
5/9
Parameter
#7 #6 #5 #4 #3 #2 #1 #0
3400 PGD
[Input type] Parameter input
[Data type] Bit path
# 5 PGD Specification of G10.9 specification (programmable diameter/radius
specification switching) is:
0: Disabled.
1: Enabled.
NOTE
1 The option for the diameter and radius setting
switching function is required.
2 If this parameter enables the specification of G10.9,
diameter/radius switching using a signal is disabled.
#7 #6 #5 #4 #3 #2 #1 #0
1006 DIAx
[Input type] Parameter input
[Data type] Bit axis
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
# 3 DIAx The move command for each axis is based on:
0: Radius specification
1: Diameter specification
