Change of Cable Inlet for Fanuc Laser C4000-MODEL E Additional Manual Page 2
Additional Manual
The change of the cable inlet of
FANAC LASER C4000-MODEL E
2/2
FANUC LTD
A-81053E-068
Description Design Date Edit.
01
040401 T.WATANABE
Title
Sheet
Draw. No.
3. Schedule of applying
Shipment from July 2004
4. Cable specification
Please use the following cable.
5. Recommended cables
○Not wiring in the duct
･ Hitachi Cable, Ltd: Single core 2PNCT 600 V, 80mm2 (The permissible current
211A)
･ LAPP CABLE: Oil flex FD-90 600V 70mm2 (The permissible current 222A)
○ Wiring in the duct
･ Hitachi Cable: Single core 2PNCT 600 V, 100mm2 (The permissible current 220A)
･ LAPP CABLE: Oil flex FD-90 600V 95mm2 (The permissible current 200A)
※ Use the cable terminal with less than 25 mm of outside diameters to pass through the
cable gland.
Also, use H sleeve terminal for the electric power cable of the laser for Europe and for
U.S.A
The cable terminal size (less than 25 mm of outside diameters)
Specification
Power cable Earth cable
For Japan M8 M8
For U.S.A H sleeve (The stick terminal) M8
For Europe H sleeve (The stick terminal) M6
※ In case of use the numerous core cable, peel off a sheath from the breaker terminal part to
the cable inlet, and insert cores one by one.
6. Cable shield
Please choose the following cable shield for single core cable. The cable shield is the
option parts of the laser oscillator for Europe.
Cable shield for single core cable ： A04B-0815-K140
Before change After change
Cable type 4 core cable Single core cable
Conductor
cross section
Over 70mm2
Over 70mm2
Outer diameter
34mm ∼ 44mm 14mm ∼ 25mm
