The Change of the Connector Color for 30i Series Additional Manual Page 2
Additional Manual
Edit.
DATE Design
Description
DRAW. NO.
A-86700EN
CUST.
01
05/10/14
New issued
Suwa
TITLE
The Change of the connector color for 30
i
series
SHEET
1 / 1
The Change of the connector color for 30i series
This document describes the change of the connector color used on PWB in the following applied
system.
Applicable system:
• 30i series
FANUC Series 30i/300i/300is/31i/310i/310is/32i/320i/320is-MODEL A
FANUC Series 31i/310i/310is-MODEL A5
1. Summary of Change
The housing color of the connector on PWB is changed. The change is only about color, and
it is not about quality and reliability.
2. Applicable Connector
It apply to the following connector.
Color change
Drawing Number Application
Before
Change
After
Change
Applicable
System
Remark
1 A63L-0001-0746#12S
Connector of Inverter
board to Main board
Black White
30i series (LCD
mounted type )
Refer to
Fig.2-1
Note) Applicable connector is the board-mounted connector for internal connection. Not for external
interface.
Fig.2-1 A63L-0001-0746#12S Before Change After Change
3. Change date
The change of the connector color applies on January 2006.
Contents Summary of The Change of the Connector Color for 30i Series Additional Manual
