Modification of the signal light in FANUC LASER C series Additional Manual Page 2
Additional Manual
TITLE
DRAW.
No.
Modification of the Indicator Light
in FANUC LASER C series
A-81053E-040
Modification of the signal light in FANUC LASER C series
1．Outline
The signal light (PATLITE) in FANUC LASER C series for CE marking is modified. Reliability of
new signal light is improved, because new signal light is equipped the LED instead of light bulb.
Luminous color changed from Orange (Old) to Yellow (New).
2．Application
FL C1000-E for CE marking, FL C2000-E for CE marking, FL C4000-E for CE marking after
manufactured in December 2002.
3．Outer dimension
New
Old
1 / 2
Page
FANUC LTD
DESCRIPTION DESIGN DATE
EDIT
New registration T. Watanabe02.12.10 01
