POWER MATE i-MODEL D/H Operation and maintenance handbook Page 307

Operation and maintenance handbook

Page of 396

/ 396

8. PARAMETERS

287

Number RemarksContents

7202

#6 NS2 : The general–purpose switches on the software

operator’s panel are used (0)/not used (1).

#7 NS0 : The software operator’s panel is used (0)/not

used (1).

7210 Numeric key used as the + direction key of the

first axis for jog feed on the software operator’s

panel

7211 Numeric key used as the – direction key of the

first axis for jog feed on the software operator’s

panel

7212 Numeric key used as the + direction key of the

second axis for jog feed on the software

operator’s panel

7213 Numeric key used as the – direction key of the

second axis for jog feed on the software

operator’s panel

7214 Numeric key used as the + direction key of the

third axis for jog feed on the software

operator’s panel

PMi–H

7215 Numeric key used as the – direction key of the

third axis for jog feed on the software

operator’s panel

PMi–H

7216 Numeric key used as the + direction key of the

fourth axis for jog feed on the software

operator’s panel

PMi–H

7217 Numeric key used as the – direction key of the

fourth axis for jog feed on the software

operator’s panel

PMi–H
