FANUC Series 16i/18i-MA
Program restart function for RISC
Specifications
A-76350E
2000.01.17
Egashira
02
2000.04.06
Revision for mark *2
2/2
Egashira
1. Outline
The program restart of the NC program that contained HPCC became possible.
However, the following limitations exist.
It is necessary to set parameter MSU (8403#1) to 1.
2. Operation
Handling applies correspondingly to a past program restart function. Please refer the
operator's manual “B-63014EN” and connecting manual “B-63003EN” for details.
3. Parameters
#7 #6 #5 #4 #3 #2 #1 #0
8403 MSU
[Data type] Bit
MSU: When G00, M, S, T, and B are used in HPCC mode,
0: an alarm is generated.
1: the instruction is executed on the CNC side.
Please set this parameter to 1 when you execute the program restart of the NC
program that contains HPCC. When this parameter is set to 0, correct restart
operation is not done.
4. Connecting
Handling applies correspondingly to a past program restart function. Please refer the
operator's manual “B-63014EN” and connecting manual “B-63003EN” for details.
5. Limitations
Please set parameter MSU (8403#1) to 1 when you execute the program restart of the NC
program which contains instruction of HPCC (G05P10000;). When this parameter is set to 0,
correct restart operation is not done.
The MDI intervention after the program restart switch is turned off can only instruct by M, S,
and T and B function. If the movement instruction is done, P/S alarm 099 is generated.
Moreover, the G05P0 instruction becomes invalid. Please do not do these instructions.
Please use the NC system software and RISC software of edition that corresponds to this
function. When it is not so, correct operation is not done.
*2
*2
*2
