FS 16i/18i/21i-TA/TB (2 or 3 paths) Rigid tapping with spindle of another path Additional Manual Page 7

Additional Manual
4. ALARM
No. Message Description
205
RIGID MODE DI
SIGNAL OFF.
(1) Although a rigid M code (M29) has been issued, rigid mode
DI signal RGTAP<G061.0> is not ON when tapping cycle
G84/G88 is executed.
(2) When an attempt is made to perform rigid tapping on
equipment having a multi-spindle function, the spindle with
which to perform rigid tapping has not been selected.
(SWS1 to SWS3<G027#0 to#2>)
(3) When an attempt is made to perform rigid tapping with the
setting for the use of rigid tapping with the spindle of
another path (parameter No. 3703 #4 SPR = 1) on a 2- or
3-
p
ath lathe, no spindle selected the command for that path.
Or, the spindles of multiple paths have been selected by a
command for the same path.
Check the spindle command selection signal (such as
<G63#3,#2>).
(4) When an attempt is made to perform rigid tapping with the
setting for the use of rigid tapping with the spindle of
another path (parameter No. 3703#4 SPR = 1) on a 2- or
3-path lathe, the spindle is in an operation mode other than
spindle control (such as Cs contour control or spindle
synchronous control).
If using this function, switch the spindle with which to
perform rigid tapping to spindle control mode before
starting rigid tapping.
Ed.
Page
Name
No.
Date
Contents
Draw u
p
FS16
i
/18
i
-TA/TB (2 or 3 path)
Rigid tapping with spindle of another path Specifications
A-78374E
2003.05.28
7/8
