FANUC Series 16i/18i Additional Manual Page 3

Additional Manual
2 Parameters
#7 #6 #5 #4 #3 #2 #1 #0
13114 DRM
[Data type] Bit
DRM The state of the diameter/radius during the program search for the the program
restart function is decided by M code to which the parameter is set.
This function is :
0: invalid.
1: available.
3419 M-code of diameter mode
[Data type] Byte
[Valid data range] 1 to 255
It is recognized that the first axis is a diameter mode during the program search for the
program restart function when parameter No.13114#6 DRM is set to “1”.
Set value 0 is invalid.
3420 M-code of radius mode
[Data type] Byte
[Valid data range] 1 to 255
It is recognized that the first axis is a radius mode during the program search for the
program restart function when parameter No.13114#6 DRM is set to “1”.
Set value 0 is invalid.
A-79980E
Sheet
Title
Draw
No.
Ed. Date Design Description
Date
Feb.04.’05 Desig. Apprv.
FANUC Series 16i / 18i – MB
DIAMETER/RADIUS DYNAMIC SWITCHING
during PROGRAM RESTART
3/4
