FANUC Series 16i/18i Additional Manual Page 4

Additional Manual
3 Notes
- The state of the starting program search for the program restart function is the
radius mode regardless of the signal (G0296/F0296) state.
DI*signal : * : Axis number
0: Radius command mode.
1: Request of diameter command mode.
DM*signal : * : Axis number
0: Radius command mode.
1: Diameter command mode.
#7 #6 #5 #4 #3 #2 #1 #0
G296 DI8 DI7 DI6 DI5 DI4 DI3 DI2 DI1
#7 #6 #5 #4 #3 #2 #1 #0
F296 DM8 DM7 DM6 DM5 DM4 DM3 DM2 DM1
- Parameter No.3419 and No.3420 are the M code number of the preventing
buffering of the following blocks.
A-79980E
Sheet
Title
Draw
No.
Ed. Date Design Description
Date
Feb.04.’05 Desig. Apprv.
FANUC Series 16i / 18i – MB
DIAMETER/RADIUS DYNAMIC SWITCHING
during PROGRAM RESTART
4/4
