3 General Information
3.1 General
All devices are mounted on a base plate made of 2 mm Electric zinc plating steel completely
finished and coated. The color is gray; Munsell N3 or RAL in gloss level and color adapted to
the FANUC surfaces.
The scales of override switches as well as other descriptions are printed with white paint. The
surface of the base plate is additionally coated in order to guarantee rub proofness.
The degree of protection is IP 54.
3.2 Assembly and Wiring
Sub Panel E is equipped with a separate ground bolt at the rear side. This bolt is to connect
with a ground strap to the common grounding system of the switchgear cabinet. The cross-
section should be at least 1.5 mm
2
.
Refer also to the description and connection details of Machine Operator's Panel Connection
Manual in the dedicated FANUC manuals.
