3.12.15
End Reading of the CNC Program
[Name]
pl_nc_upend2
[Syntax]
#include <pmclib.h>
short
pl_nc_upend2(unsigned short path);
[Arguments]
Input
path: The CNC path number(from 1)
Set the CNC path number. When you set zero, first path CNC is
selected.
Output
---
[Return]
0: Normal completion.
-11: The function pl_nc_upstart2() is not called.
1: The "path" is invalid.
[Description]
This function ends the reading of the CNC program.
You should call pl_nc_upend2() after the calling of the pl_nc_upload2().
When you use this function, you cannot use the conventional function
related to the CNC program operation in "C library for C executor"
together.
[Related Function]
cnc_upstart(), cnc_upload(), cnc_upend()
