1. Fanuc
  2. Series 30i/300i/300is/31i/310i/310is/32i/320i/320is-MODEL A

Series 30i/300i/300is/31i/310i/310is/32i/320i/320is-MODEL A Additional Manual Page 55

Additional Manual
Series 30i/ 31i/ 32i-A
C executor library for conversion
Programming manual
01 04.05.06
S. Hasegawa
New registration
B-64183EN/01
EDIT
DATE
DESIG.
DESCRIPTION
55/226
DRAW.NO.
key-in line (0 to 60).
If 0, a negative value, or a value greater than 60 is set, the
specification of 60 is assumed.
LA: Display attribute
When echo-back display is to be provided on the key-in line
(KYDSP = 1), set the attribute of characters.
Normal attribute: Color code + 0x00
Reverse attribute: Color code + 0x10
Blink attribute: Color code + 0x08
Color code : Black:0x00, Red:0x20, Green:0x40, Yellow:0x60,
Blue:0x80, Magenta:0xA0, Cyan:0xC0, White:0xE0
PA: Prompt display attribute
When prompt display is to be provided (KYPRM = 1), set the
attribute of prompt characters.
Normal: Color code+0x00
Reverse: Color code+0x10
Blink: Color code+0x08
Color code: Black:0x00, Red:0x20, Green:0x40, Yellow:0x60,
Blue:0x80, Magenta:0xA0, Cyan:0xC0, White:0xE0
X: Column position of the key-in line (0 to maximum display
column position)
When the key-in line display position is to be changed (KYDPS =
1), set a new column position. When the display position is not to
be changed (KYDPS = 0), the column position is 0.
Y: Line position of the key-in line (0 to maximum display line
position)
When the key-in line display position is to be changed (KYDPS =
1), set a new line position. When the display position is not to be
changed (KYDPS = 0), the line position will be 23.
PN: Number of prompt characters
When prompt display is to be provided (KYPRM = 1), set the
number of characters of a prompt character string. A value from
1 to 17 (including a NULL character) can be specified.
STRING: Prompt character string
When prompt display is to be provided (KYPRM = 1), set a
character string. In the case of access of short type, the byte order
differs from that used with the C language board. Note that a
character string is set in the order from a high byte to a low byte.
Output
---
