1. Fanuc
  2. FS 16i/18i/21i Virtual MDI Key (HSSB type)

FS 16i/18i/21i Virtual MDI Key (HSSB type) Additional Manual Page 10

Additional Manual
9
Edit
A
pprv.Desig.
Sheet
Title
Draw
No.
/
12
Date
Desi
g
n
Descri
p
tion
Date
FANUC Series16i/18i/21i
Specification for
Virtual MDI Key(HSSB type)
A
-76454E
2001.10.25
K.Hayashi
T.Nakazato
SYSTEM MONITOR MAIN MENU 60M3-XX
1.
SYSTEM DATA LOADING
2.
SYSTEM DATA CHECK
3.
SYSTEM DATA DELETE
4.
SYSTEM DATA SAVE
5.
SRAM DATA BACKUP
6.
MEMORY CARD FILE DELETE
7.
MEMERY CARD FORMAT
10.END
*** MESSAGE ***
SELECT MENU AND HIT SELECT KEY
[SELECT][ YES ][ NO ][ UP ][ DOWN ]
[ PREV ] [ NEXT ]
Fig. A1-2 Bootstrap operation screen
In this screen, you can operate by touching directly the soft-key image (“[SELECT]”, “[ YES
]” , , , ). When key-touch is accepted, display unit beeps.
“[PREV]” means the soft-key of CRT. “[NEXT ]” means the soft-key of CRT.
The respective function of the bootstrap is described in the following manual.
FANUC Series 16i / 18i / 21i / 160i / 180i / 210i –MODEL A
maintenance manual(B-63005EN )
FANUC Series 16i / 18i / 21i / 160i / 180i / 210i –MODEL B
maintenance manual (B-63525EN )
