FS 16i/18i/21i Virtual MDI Key (HSSB type) Additional Manual Page 2

Additional Manual
1
Edit
A
pprv.Desig.
Sheet
Title
Draw
No.
/
12
Date
Desi
g
n
Descri
p
tion
Date
FANUC Series16i/18i/21i
Specification for
Virtual MDI Key(HSSB type)
A
-76454E
2001.10.25
K.Hayashi
T.Nakazato
《Index》
１． Outline.....................................................................................................................................2
２． Specification ..........................................................................................................................2
2.1 Layout of Virtual MDI Key while CNC screen display ................................... 2
2.2 Layout of Virtual MDI Key while PMC high resolution screen display ..... 3
2.3 Detail of keys............................................................................................................... 4
３． Restrictions ............................................................................................................................5
Appendix Maintenance operation at power-on .....................................................................7
1 Bootstrap system operation ..................................................................................... 8
2 CNC initializing operation ..................................................................................... 10
FANUC Series 16i /18i /21i
SPECIFICATION
for
Virtual MDI Key(HSSB type)
Previous page
Next page

Contents Summary of FS 16i/18i/21i Virtual MDI Key (HSSB type) Additional Manual

  • Page 1TECHNICAL REPORT (MANUAL) No.TMN 01/ Date : Nov. 8, 2001 General Manager of Software Development Center FANUC Series 16i/18i/21i Virtual MDI Key(HSSB type) 1. Communicate this report to: Your information only ○ GE Fanuc-N, GE Fanuc-E FANUC Robotics MILACRON ○ Machine tool builder Sales agency End us
  • Page 2FANUC Series 16i /18i /21i SPECIFICATION for Virtual MDI Key(HSSB type) 《Index》 １． Outline .....................................................................................................................................2 ２． Specification .........................................................
  • Page 31． Outline This manual explains the operation for Virtual MDI key. This function enables program editing or data alternation by the virtual keyboard displayed on touch pane, instead of MDI key. 2． Specification 2.1 Layout of Virtual MDI Key while CNC screen display CNC screen “EDIT” key “CANCEL” key
  • Page 42.2 Layout of Virtual MDI Key while PMC high resolution screen display Full key (See through) CHAPTER select Softkey Full key Display ON/OFF switching key Function key (Display①) Position Offset Message Operation Display①／② RETURN menu key Program System Custom CONTINUE menu key switching key Cursor
  • Page 52.3 Detail of keys 1) Input key “ＥＮＴＥＲ”、”ＥＮＴ” on Virtual MDI key are assigned to Input key. 2) Cancel key “BACK SPACE”、”CAN” on Virtual MDI key are assigned to Cancel key. 3) Shift key “SHFT” on Virtual MDI key are assigned to Shift key. “ ^ ” is displayed while “shift” state, and the character arra
  • Page 65) Custom key (CUST) ・ The screen, developed by macro executor, can be displayed at the left top of Virtual MDI key in the CNC screen. 40 characters and 16 lines can be displayed. 6) Operation key (OPER) ・ When the user’s screen, developed by C Language executor or FAPT Picture, is assigned to scree
  • Page 7④ When Virtual MDI key (HSSB type) is used, screen for VGA(with background color) can not be used together. FANUC Series16i/18i/21i Title Specification for Virtual MDI Key(HSSB type) Draw No. A-76454E Edit Date Design Description Sheet 6/12 Date 2001.10.25 Desig. K.Hayashi Apprv. T.Nakazato
  • Page 8Appendix Maintenance operation at power-on In this chapter, the CNC maintenance operation at power-on is described. According to the operation on the display unit with touch screen, the following maintenance operation can be performed. ● Bootstrap system operation -Load the system file from a memory
  • Page 91 Bootstrap system operation Turn on the power of the display unit with touching the upper left part on the touch screen. In a little while, the maintenance operation screen shown in Fig 3-1 is displayed. Tu r n on power wit h Touch scr een t ou ch in g t h is pa r t SELECT THE MAINTENANCE OPERATION
  • Page 10SYSTEM MONITOR MAIN MENU 60M3-XX 1.SYSTEM DATA LOADING 2.SYSTEM DATA CHECK 3.SYSTEM DATA DELETE 4.SYSTEM DATA SAVE 5.SRAM DATA BACKUP 6.MEMORY CARD FILE DELETE 7.MEMERY CARD FORMAT 10.END *** MESSAGE *** SELECT MENU AND HIT SELECT KEY [SELECT][ YES ][ NO ][ UP ][ DOWN ] [ PREV ] [ NEXT ] Fig. A1-2 B
  • Page 112 CNC initializing operation Turn on the power of the display unit with touching the upper right part on the touch screen. In a little while, the CNC initializing operation screen shown in Fig 3-3 is displayed. Tu r n on power wit h Touch Pa n el Scr een t ou ch in g t h is pa r t SLOT CONF IGURATIO
  • Page 12IPL OPERATION 0123456789-+/*=()[],.#&@? ABCDEFGHIJKLMNOPQRSTUVWXYZ

    < P↓>< ↑ >< ↓ >< ← >< → > ↑ KEY 1 [ ] ← → KEY 2 [ ] ↓ *** MESSAGE *** SELECT KEY AND HIT [SELECT] KEY [SELECT][ YES ][ NO ][ ][

  • Page 132.1 Operation of CNC initializing 1) You can select the data by moving the cursor by touching the arrows ↑、↓、←、→ in the middle of screen. Select the desired character by the cursor and touch [SELELCT]. Then, the message “SELECT OK? HIT YES OR NO” is displayed. 2) If you touch [YES], the selected cha
  • Page 142.2 List of initializing operation Initializing operation Selected character KEY 1 KEY 2 Clear all memory Clear parameters and offset data Clear part program Clear PMC RAM X O Reset OT alarm P Reset PS101 (Power off while program editing) Note) Do not care t
