2.2 Compensation data
2.2 Compensation data2.2 Compensation data
2.2 Compensation data
Compensation data is set using 128 straightness compensation points.
3.
3. 3.
3. Parameter
ParameterParameter
Parameters
ss
s
#7 #6 #5 #4 #3 #2 #1 #0
3605 IST
[Data type] Bit axis
IST: Specifies whether to use the interpolating straightness compensation
function.
0: Do not use.
1: Use.
4. Alarm and Message
4. Alarm and Message4. Alarm and Message
4. Alarm and Message
No. Message Meaning
5046 ILLEGAL PARAMETER(ST. COMP) The parameter for setting slope compensation is
incorrect. This alarm occurs in the following case:
!
Invalid axis numbers have been assigned to move
or compensation axes.
!
Parameter (No.13381-No.13386) is incorrect.
5321 S-COMP. VALUE OVERFLOW
!
The value set for straightness compensation has
exceeded maximum value 32767. Do not fail to
perform reference point return manually after
generating this alarm.
5. CAUTION
5. CAUTION5. CAUTION
5. CAUTION
- This function is an option function.
- When this option is effective, 128 Straightness compensation points function becomes
effective, too.
- The specification of this function applies correspondingly to the specification of 128
Straightness compensation points function excluding the correction method. Please refer
to "128 Straightness compensation points specifications (A-76424EN)" for details.
- S-RAM 768byte is necessary to use this function
- Stored pitch error compensation option is necessary to use this function.
