FANUC AC Spindle Motor ai Series IP65 Models Additional Manual Page 12

Additional Manual
A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS
3.3 MODEL α1.5/8000i (IP65) (FLANGE MOUNTING TYPE)
- 12 -
Previous page
Next page

Contents Summary of FANUC AC Spindle Motor ai Series IP65 Models Additional Manual

  • Page 1A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS 1 SPECIFICATIONS -1-
  • Page 2A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS Series αi series IP65 models Model α0.5/10000i (IP65) α1/8000i (IP65) α1.5/8000i (IP65) Item A06B-1481-B**5 A06B-1482-B**5 A06B-1483-B**5 Cont. rated rated kW 0.55 0.9 0.9 Output (HP) (0.74) (1.2) (1.2) (*1) S2 time min 15 15 10 Short time r
  • Page 3A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS Series αi series IP65 models Model α2/8000i (IP65) α3/8000i (IP65) α6/8000i (IP65) Item A06B-1484-B**5 A06B-1485-B**5 A06B-1486-B**5 Cont. rated rated kW 1.5 2.2 3.0 Output (HP) (2.0) (3.0) (4.0) (*1) S2 time min 15 30 30 Short time rated kW
  • Page 4A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS (*1) The rated output is guaranteed at the rated voltage. (Amplifier input 200V input: 200/220/230V AC +10% -15%, 50/60 Hz ±1Hz 400V input: 400/480V AC +10% -15%, 50/60 Hz ±1Hz) If the input voltage fluctuates, it is possible that the rated
  • Page 5A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS 2 Reference OUTPUT/TORQUE CHARACTERISTICS Calculation for torque Torque T can be obtained by the following equation. T[N⋅m]=P[kW]×1000/0.1047/N[min-1] P[kW]: Motor output -1 N[min ]:Motor speed When the unit of T is [kgf⋅m], T[kgf⋅m]=P[kW]×1
  • Page 6A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS 2.1 MODEL α0.5/10000i (IP65) Output Torque [kW] [N⋅m] 1.6 4 15min, S3 40% operating zone 1.2 1.1kW 3 15min, S3 40% operating zone 0.9kW 0.8 2 0.55kW 0.4 Continuous 1 0.37kW Continuous operating zone operating zone 3000 3000 0 0 0 2000 4000 6
  • Page 7A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS 2.3 MODEL α1.5/8000i (IP65) Output Torque [kW] [N⋅m] 5 25 10min, S3 15% operating zone 4 3.7kW 20 10min, S3 15% Continuous 3 operating zone 15 operating zone 2.2kW 2 10 0.9kW 1 5 Continuous 1500 operating zone 1500 0 0 0 2000 4000 6000 8000
  • Page 8A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS 2.5 MODEL α3/8000i (IP65) Output Torque [kW] [N⋅m] 8 40 30min, S3 40% operating zone 6 5.5kW 30 Continuous 30min, S3 40% operating zone 4 operating zone 20 3.0kW 2.2kW 2 2.0kW 10 Continuous operating zone 1500 1500 0 0 0 2000 4000 6000 8000
  • Page 9A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS 3 EXTERNAL DIMENSIONS Model name Section Model α0.5/10000i (IP65) (flange mounting type) 3.1 Model α1/8000i (IP65) (flange mounting type) 3.2 Model α1.5/8000i (IP65) (flange mounting type) 3.3 Model α2/8000i (IP65) (flange mounting type) 3.4
  • Page 10A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS 3.1 MODEL α0.5/10000i (IP65) (FLANGE MOUNTING TYPE) - 10 -
  • Page 11A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS 3.2 MODEL α1/8000i (IP65) (FLANGE MOUNTING TYPE) - 11 -
  • Page 12A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS 3.3 MODEL α1.5/8000i (IP65) (FLANGE MOUNTING TYPE) - 12 -
  • Page 13A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS 3.4 MODEL α2/8000i (IP65) (FLANGE MOUNTING TYPE) - 13 -
  • Page 14A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS 3.5 MODEL α3/8000i (IP65) (FLANGE MOUNTING TYPE) - 14 -
  • Page 15A-56590-1259E FANUC AC SPINDLE MOTOR αi SERIES IP65 MODELS 3.6 MODEL α6/8000i (IP65) (FLANGE MOUNTING TYPE) - 15 -
