SERIES 15-150 MODEL B Programming manual Page 94

Programming manual

B–62073E–2/03
4.CONVERSATIONAL MACRO FUNCTION
91
OT alarm flag 3
I.D No.
(#8997)
Bit name Information contents
Error
code
OTPCD (01H) Position coder disconnection has
been detected
OT 116
OTADH (02H) External data input/output I/F signal
upper rank 4 bits are not defined
Address (major category) is not
specified
OT 120
OTADL (04H) External data input/output I/F signal
lower rank 4 bits are not defined
Address (minor category) is not
specified
OT 121
OTMOV (08H) More than 5 displays simulta-
neously requested for external;
operator message or external alarm
message display
OT 122
7
OTNOM (10H) Because there is no specified mes-
sage number in cancel of external
operator message or external alarm
message, it cannot be cancelled.
OT 123
7
OTOUT (20H) Output again requested during
external data output, Or, output
requested for address with no out-
put data.
OT 124
OTNUM (40H) Value specified outside range
0–999 for number of external oper-
ator message or external alarm
message
OT 125
OTSRH (80H) There is no external data input pro-
gram number or number specified
by sequence number search. Or,
there is no program number speci-
fied by workpiece number search.
Tool data pot number and offset
amount input/output was requested,
but when power turned on tool
number input was not performed,
or, there is no tool data corre-
sponding to inputted tool number.
OT 126
