Terminal module A -Connection Manual Additional Manual Page 3
Additional Manual
EDIT DATE DESIG.
TITLE
DESCRIPTION
DRAW NO
A-80034E
SHEET
CUST
3
/
9
3. Connection of Each Part
3.1 Pin Assignment
Terminal and Connector pin assignment of the Terminal Module
XT150A (YOSHIDA PX7-32A) XT150B (YOSHIDA PX7-32A)
X150 (HIROSE HIF3CB-50PA-2.54DSA)
A connector specification of flat cable side is
HIF3BA-20D-2.54R
Note) For detailed allocation of DI/DO address, refer to connection manual of Connector Panel I/O Module.
Note) Output Pins shaded by are in pairs. Only one in each pair is usable.
10V
2DICOM
3Xm+0.2
4Xm+0.3
5DICOM
6Xm+0.6
7Xm+0.7
8 +24E
9Xm+1.2
10 Xm+1.3
11 +24E
12 Xm+1.6
13 Xm+1.7
14 +24E
15 Xm+2.2
16 Xm+2.3
1 +24E
2Xm+2.6
3Xm+2.7
40V
5 Yn+0.2
6 Yn+0.3
70V
8 Yn+0.6
9 Yn+0.7
10 0V
11 Yn+1.2
12 Yn+1.3
13 0V
14 Yn+1.6
15 Yn+1.7
16 0V
17 +24E
18 DICOM
19 Xm+0.0
20 Xm+0.1
21 DICOM
22 Xm+0.4
23 Xm+0.5
24 +24E
25 Xm+1.0
26 Xm+1.1
27 +24E
28 Xm+1.4
29 Xm+1.5
30 +24E
31 Xm+2.0
32 Xm+2.1
17 +24E
18 Xm+2.4
19 Xm+2.5
20 0V
21 Yn+0.0
22 Yn+0.1
23 0V
24 Yn+0.4
25 Yn+0.5
26 0V
27 Yn+1.0
28 Yn+1.1
29 0V
30 Yn+1.4
31 Yn+1.5
32 +24V
A1 B1
A2 B2
A3 B3 Yn+0.2
A4 Yn+0.6 B4 Yn+0.0
A5 Yn+1.0 B5 Yn+0.1
A6 Yn+1.2 B6 Yn+0.3
A7 Yn+0.5 B7 Yn+0.7
A8 Yn+1.1 B8 Yn+1.3
A9 Yn+1.4 B9 Yn+1.4
A10 Yn+1.5 B10 Yn+1.5
A11 Yn+1.6 B11 Yn+1.6
A12 Yn+1.7 B12 Yn+1.7
A13 B13
A14 B14
A15 B15
A16 B16
A17 B17
A18 Yn+0.4 B18
A19 B19
A20 B20
A21 B21
A22 B22
A23 B23
A24 0V B24 0V
A25 0V B25
